JSP 12-EC C

Cordless jigsaw 12 V

Order number: 531316

EAN No.: 4030293251564

Local dealers
Battery voltage12 V
Battery capacity2.5 / 5.0 Ah
Orbit rate, no load800 - 3000 rpm
Stroke23 mm
Pendulum stroke stages4 Steps
Speed settings1-5 +A Steps
Pivoting range0-45 °
Max. material thickness, wood90 mm
Max. material thickness, metal10 mm
Dimensions WxLxH220 x 69 x 183 mm
Weight without battery pack1.46 kg

Advantages

  • New generation of brushless motors delivering high efficiency and performance
  • Continuously variable cutting speed setting via potentiometer wheel with automatic start-up in position A
  • Tool-free saw blade change with quick-clamping system and eject function
  • Orbital stroke: 4 settings for higher cutting rate
  • Double roller jigsaw blade guide for precise cuts with accurate angles
  • Free view of the marking thanks to integrated blow function
  • Perfect ergonomics thanks to ideally located SoftGrip surfaces
  • Low-vibration and comfortable sawing
  • Saw bench adjustment for bevel cuts of up to 45°, 0-lock. Can be set off backwards for sawing close to edges
  • Stable base plate with removable plastic guide block for the protection of delicate surfaces
  • Electronic management system (EMS) protects the machine, extends the service life, and increases efficiency
  • With automatic start-up, overload protection
  • Vacuum flange Ø 27 mm, for a cleaner workplace and clear view of the cut
  • Removable chip screen, for tear-free cuts and for guiding the saw blade
  • Integrated LED lamp for optimum illumination of the work area.
  • LED battery capacity display
  • FLEX battery system: suitable for all FLEX 12 V battery packs. Delivery does not include battery and charger
