CS 60 WET 110/CEE-UK

Diamond stone cutter for wet cuts, mitre cuts up to 45 °, with GFCI circuit breaker

Standard supply
Technical data
Power consumption1400 W
Power output830 W
Voltage110 V
Frequency50/60 Hz
Cutting depth60 mm
Cutting depth with guide rail54 mm
Cutting depth, mitre cut (45°)5-44 mm
Cutting depth, mitre cut with guide rail (45°)38 mm
No-load speed6200 rpm
Diamond disc diameter170 mm
Diamond disc hole22.2 mm
Pivoting range45 °
Cable length4.0 m
Dimensions WxLxH360 x 280 x 170 mm
Weight4.5 kg


  • Ideal for: Inserting water grooves in window sills or steps, work tops, facade slabs, terazzo slabs in garden design & landscaping, joint renovation in the floor
  • GFCI operator protector circuit breaker: integrated in cord
  • Quick-fit brass coupling: for 1/2 water hose
  • High-performance motor: extra powerful for stone cutting and joint milling
  • Continuous cut depth setting from 0-60 mm, with rail guide up to 54 mm. In the mitre cut from 0-44 mm, with guide rail up to 38 mm
  • Continuous angle adjustment for mitre cuts from 0-45°
  • Cut marking at the base plate from 0°/30°/45° for rapid orientation
  • High-quality magnesium die-castings for protective cover and base plates
  • Motor protection made of rubber prevents the direct intake of spray water
  • Water supply: for an effective cooling of the diamond blade
  • Spindle lock

Matching accessories

  • D-TCS P 170x22,2
    Diamond cutting disc
  • D-TCS T-Jet 170x22,2
    Diamond cutting disc
  • 2 Versions
    Guide rail GRS
  • GRS-V
    Connector for guide rail GRS
    Trolley L-BOXX®
  • D-TCS S 170x22,2
    Diamond cutting disc
  • Carrying case L-BOXX®
  • TKE CS 60 Wet II
    Case insert
